IN THE BOX | |
---|---|
Sales Package | Solid State Logic SSL 2 MKII USB-C Audio Interface USB-C to USB-C Cable (3.3') USB-C to USB-A Adapter |
General | |
---|---|
Brand | Solid-State-Logic |
Model | SSL 2 MKII |
Color | black |
Display | 2x Multi-Segment LED Meter |
Channels of I/O | Analog: 2 Inputs / 2 Outputs at 192 kHz |
Maximum Sampling Rate | 192 kHz / 32-Bit |
Number of Microphone Inputs | 2 |
Input Level Adjustment | 2x Knob |
Gain/Trim Range | Mic Inputs: Up to 64 dB |
Analog Audio I/O | 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input 2x 1/4" TS Line/Hi-Z Input 2x 1/4" TRS Headphone Output 2x 1/4" TRS Balanced Monitor Output |
Phantom Power | 48 V, Selectable On/Off (Selectable on Individual Inputs) |
Host Connection | 1x USB-C |
Host Connection Protocol | USB 2.0 |
Frequency Response | Mic Inputs: 20 Hz to 20 kHz ±0.1 dB Line, Hi-Z Inputs: 20 Hz to 20 kHz ±0.05 dB Line, Headphone, Monitor Outputs: 20 Hz to 20 kHz ±0.05 dB |
Maximum Input Level | Mic Inputs: +5.5 dBu Line Inputs: +24 dBu Hi-Z Inputs: +15 dBu |
Maximum Output Level | 1/4" Line Outputs: +14.5 dBu Headphone Outputs: +13 dBu |
Impedance | Mic Inputs: 1.2 Kilohms Line Inputs: 10 Kilohms RCA Line Outputs: < 1 Ohm Hi-Z Inputs: 1 Megohm Headphone Outputs: 10 Ohms Monitor Outputs: 1 Ohm |
Dynamic Range | 1/4" Hi-Z: 116 dB Line Inputs: 117 dB Mic Inputs: 116.5 dB Headphone Outputs: 119.5 dB Line Outputs: 120 dB |
THD+N | Mic/Line/Hi-Z Inputs: < 0.005% (at -1 dBFS) Monitor Outputs: < 0.002% (at -1 dBFS) RCA Line Outputs: < 0.0025% (at -1 dBFS) Headphone Outputs: < 0.002% (at -1 dBFS) |
EIN | Mic Inputs: -130.5 dBu A-Weighted (150-Ohm Source) |
Sample Rates | Up to 192 kHz |
Bit Depths | Up to 32-Bit |
Latency | < 1 ms at 48 kHz (Input to Output) |
Dimension | |
---|---|
Dimension | 23.4 x 15.7 x 6.9 cm |
Weight | 0.9 kg |
Warranty | |
---|---|
Warranty Type | Official Manufacturer Warranty |
Warranty Period | 1 year |
